Scharmann WF 240 Boring Mill
Details
| Make: | Scharmann |
| Type: | WF 240 |
| Built: | 1968 / 2014 |
Description
The Scharmann WF240 is a robust, floor-type horizontal boring mill ideal for large workpieces and heavy-duty metal cutting.
Originally built in 1968 and retrofitted in 2014, this machine combinesclassic mechanical strength with modernized electrical and control systems.
With 5,500 mm X-axis travel and a powerful Ø125 mm spindle, it’s perfectly suited for demanding tasks in energy, Shipyard, Rail and heavy machinery manufacturing.
| Travels | |
| Longitudinal Movement (X-Axis) | 5.500 mm |
| Vertical Movement (Y-Axis) | 3.200 mm |
| Spindle Movement (Z-Axis) | 600 mm |
| RAM Movement (W-Axis) | 600 mm |
