| manufacturer: | ELB |
| type: | Smart BD 10 Comfort |
| built: | 2009 |
| control: | B&R Comfort |
The surface and profile grinding machine ELB Smart BD10 from 2009 is equipped with a B&R "Comfort" controller. This control offers automatic grinding cycles for face and plunge-cut grinding in combination with graphic-supported input and a simple teach-in function. A magnetic clamping plate with a clamping surface of 1,000 x 600 mm is mounted on the working table of the ELB Smart BD10. The electric straight dresser with automatic dress compensation is mounted above the headstock. The grinding spindle is supported axially and radially backlash-free, it is driven by a frequency-controlled 10 kW three-phase motor and can accommodate grinding wheels up to 400 mm diameter and 100 mm width. A wet grinding device with coolant tank and paper band filter complete the equipment of this very well maintained machine.
Technical Equipment/Features
| grinding range: | |
| grinding length | 1.000 mm |
| grinding width | 600 mm |
| grinding height (from working table on) | 600 mm |
| table load (on magnetic plate) | 1.000 kg |
| magnetic table: | |
| clamping area | 1.000 x 600 mm |
| height about | 80 mm |
| construction | Querpolteilung |
| pole pitch | 18 mm |
| weight about | 361 kg |
| air core drilling with sinter metal use 2-rowed | |
| arranged in standard construction |
| X-axis-longitudinal table movement: | |
| table clamping size | 1.360 x 590 mm |
| table longitudinal stoke | max. 1.100 mm |
| power X-movement | hyraulic |
| Z-axis-vertical movement grinding disk: | |
| automatical cross path | max. 560 mm |
| power Z-movment | ball screw |
| resolution | 0,001 mm |
| rapid | max. 2.000 mm/min |
| Y-axis - vertical movement grinding disk: | |
| power Y-movement | ball screw |
| resolution | 0,001 mm |
| rapid | max. 1.500 mm/min |
| electrical straight dresser: | |
| positioning | mounted above the headstock |
| dressing width | 1-105 mm |
| diamond vertical adjustment max. | 80 mm |
| diamond taper | MK 0 |
| dresser diamond | 0,75 Karat |
| incl. automatic compensation |
| grinding spindle head: | |
| motor-version | DS-Flanged motor |
| power | 10 kW |
| grinding spindle speed | 1.000 - 3.000 min-1 three-phase current |
| spindle bearing | axial and radial back-lash free |
| grinding spindle size | 400 x 100 x 127 mm |
| ELB grinding programm "Comfort": |
| • Grinding function surface grinding • Grinding function infeed grinding • Grinding function ECO-grinding (combined plunge and surface grinding) • Grinding function each with stored automatical grinding cycle • Easy handling for manual and automatical grinding • Digital positioning display • Display of currenty settings • Automatical dressing incl. dressing compensation • Graphic-supported input and teach-in function |
| Equipment: |
| • Electro-Permanent-Magnet clamping plate 1.000x600mm • Wet grinding device with coolant tank, tank capacity 360l, coolant pump, power 52l\min., splash water protection, coolant nozzle with mounting • Universal -paper filter unit, filter paper width 710mm, cleaning power 80l\min. • Electronic straight dresser • Magnetic plate supply faciltiy with adheshion force regualtion (30 – 100%) • Internal flushing incl. spray gun • Machine light |
